The B+M Key M.2 to 2.5 Gigabit Ethernet Adapter uses a high-performance Intel I226-V Ethernet controller. The Intel I226-V controller has a Base-T copper network interface that provides a compact single-port integrated Multi-Gigabit (2.5G) – MDI (copper) standard IEEE802.3 Ethernet interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, and 10BASE-TE connections.
| Applicable Network |
2.5G server network card |
| Main Controller |
Intel(R) I226-V |
| Bus Type |
M.2 B+M KEY |
| Media Interface |
1 x RJ45 copper cable |
| Transmission Rate |
2.5G/1000/100Mbps |
| Network Topology |
2500BASE-T, 1000BASE-T, 100BASE-TX, 10BASE-TE IEEE 802.3bz, IEEE 802.3, IEEE 802.3x, IEEE 1588, IEEE 802.3az
- Energy Efficient Ethernet (EEE) |
| Management Function |
IPMI transmission via SMBus or NC-SI, iSCSI boot, WoL, PXE remote boot, VLAN filtering |
| Operating System |
Microsoft Windows 10 32/64-bit |
| Operating Temperature |
0 ~ 55 ℃ (32 ~ 131℉) |
| Storage Temperature |
-40 ~ 70℃ (-40 ~ 158℉) |
| Certification |
FCC, CE, RoHS |
| Storage Humidity |
90% non-condensing relative humidity at 35℃ |
