VD100 Dev Board & Kit with AMD Versal AI Edge XCVE2302

VD100 Dev Board & Kit with AMD Versal AI Edge XCVE2302
VD100 Dev Board & Kit with AMD Versal AI Edge XCVE2302
This product qualifies for free shipping
This block is set to appear automatically on products above a certain price, which may qualify for free shipping or other perks.
  • Stock: In Stock
  • Model: VD100 V2.0
  • SKU: VD100 V2.0
190 samples sold
$1,824.00
Product Description

Equipped with a multitude of peripherals, VD100 is the ideal development board for your applications based on AMD Versal™ AI Edge XCVE2302 devices. The pluggable module offers you the flexibility to customize your own carrier board for mass production.

The Versal™ AI Edge series delivers high performance, low latency AI inference for intelligence in automated driving, predictive factory and healthcare systems, multi-mission payloads in aerospace, and a breadth of other applications. As an adaptive compute acceleration platform, Offers AIE-ML and DSP hardware acceleration engines, along with multiple high-speed connectivity options. support a breadth of workloads common in edge applications including AI inference, image processing, and motion control.

Applications

  • Vision

    ● AI Edge Box

    ● Machine Vision Cameras

    ● Medical Imaging Devices

  • Automotive

    ● Edge Sensor (e.g., radar, LiDAR, vision)

    ● Domain Controller Offload

    ● Sensor Processing, Aggregation, and Fusion

  • Industrial

    ● Collaborative Robotics

    ● Converged Networking

    ● Industrial-Grade PCs

  • Video and Image Processing

    ● Unmanned Aerial Vehicles

    ● MILCOM Radio

    ● Data and Signal Processing Systems



Key Features

  • System-on-Module

    ● AMD Versal™ AI Edge SoC:
    ◆ Dual-core Arm® Cortex-A72
    ◆ Dual-core Arm Cortex-R5F
    ◆ 7 nm FinFET+ FPGA fabric
    ● Pluggable module with 2 x Samtec board-to-board connectors
    ● 4 GByte (64-bit) DDR4 SDRAM
    ● 64 MB QSPI Flash
    ● 32 GB eMMC Flash
  • Base Board

    ● PCIE 4.0 x4
    ● 2 x SFP+ Slots (up to 12.5Gbps)
    ● 2 x Gigabit Ethernet (1 x PS + 1 x PL)
    ● 1 x UART
    ● 2 x 4 lane MIPI on PL
    ● 2 x CAN on PS
    ● 1 x USB 2.0
    ● EEPROM: 4-Kbit I2C Serial EEPROM + 1 x Temperature sensor (LM75)
    ● 1 x RTC (Real-time clock)
    ● 12V single supply
    ● Dimensions: 182 x 107 mm form factor

Product Information

  • Specifications
  • What's Inside
Development Board Features

Featuring the AMD Versal AI Edge XCVE2302-SFVA784-1LP-E-S Adaptive SoC

Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD Versal AI Edge based application.


* The VD100 development board consists of a pluggable V100 SoM and base board. If you want to purchase the V100 SoM only, please check the
