Interface Function Display
Product Parameters
PZSDR Main Parameters
SDR Module | P201Pro |
RF Chip | AD9361 |
Frequency Range | 70M-6Ghz |
Signal Bandwidths | 200K-56Mhz |
Power Amplifier | 2 Channel of TX |
FPGA Chip | XC7Z020-2CLG400I |
Processor Core | Dual Cortex-A9、766Mhz |
Logic Cells | 85K |
DDR3 | 1GB |
QSPI FLASH | 256Mb |
E2PROM | 256Kb |
RF Clock | 40M VCTCXO(0.5PPM)/ipex input/External input
(Default 40M VCTCXO） |
Gigabit Ethernet | 1 |
USB OTG | 1 |
UART | 1 |
JTAG | 1 |
SD卡 | 1 |
GPS | 1 |
PPS/10M Input | 1 |
External input | 1 |
Expansion Port IOs | 16 x 3.3V IO、4 x 1.8V IO |
Form Factors | Board：115x70x2.2mm with Shell：125x75x23mm |
Protection Class | All External Interfaces are Protected againstStatic Electricity,Clock/RF are Shielded |
Power Supply | 8-36V Ultra-wide Voltage Supply (Limit 50V) |
Working Temperature | -40°C~+85°C |
Product Dimensions
Rich Support Resources
Porting & OpenSource Support | 1. PlutoSDR 2. UHD 3. FMCCOMS3 4. AD9361 Non-Operating System Engineering |
Open Source Software Packages | 1. vivado2019.1 2. ubuntu-18.04.4 3. GNU Radio 4. SDRangel 5. SDR# 6. Matlab Simulink 7. Gqrx SDR 8. PYNQ |
Customisation & Support | Provide Customised Services, Professional Technical Support, Constantly Updated Demos |
