Product Description
The AXP392 FPGA development board equipped with the PANGO Titan2 series device, delivers standout performance with fast DDR4 SDRAM, QSPI Flash, PCIe, 3G-SDI, SFP+.
Provide high-speed communication (PCIe, SFP+) and video applications (3G-SDI).
Applications
● Communication
● Image and video processing
● Data analysis
● Network information security
● Instrumentation
Key Features
System-on-Module
● PANGO Titan-2 PG2T390H:◆ 28 nm FPGA fabric
◆ HSSTHP up to 13.125 Gbps Transceivers
● Pluggable module with 2 x Panasonic board-to-board connectors
● 4 GByte (64-bit) DDR4 SDRAM
● 16 MB QSPI FlashBase Board
● 1 x PCIe® Gen3 ×8
● 4 x SFP+ (per line 10Gbps)
● 1 x UART (USB to UART)
● 4 x SDI (2 x SDI in + 2 x SDI out)
● 1 x Micro SD
● 2x 40-pin Expansion Port (40 pin 2.54mm spacing, with 34 IOs, connected to ALINX modules such as binocular cameras, TFT LCD screens, high-speed AD modules, etc.)
● user I/Os
◆ 34 FPGA I/Os
● LED (1 x PWR + 1 x RXD + 1 x TXD + 4 x LED) KEY (4 x KEY)
• 12V single supply
● Dimensions: 215 x 111 mm form factor
- Specifications
- What's Inside
Development Board Features
Featuring the PANGOMICRO Titan2 PG2T390HFFBG900 Adaptive
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any PANGOMICRO Titan2 based application.
* The AXP392 development board consists of a P390 SoM and base board. If you want to purchase P390 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.
What's Inside the Box
ALINX PANGOMICRO Titan2 PG2T390H development board and Some accessories
The FAN8060 Heatsink Kit is an optimal cooling solution for ALINX FPGA and modules – it is low-profile and covers the whole module surface.
| System-on-Module | 1 | Base Board | 1 |
|---|---|---|---|
| Mini USB Cable | 1 | Heatsink Kit (preinstalled) | 1 |
| 12V Power Adapter | 1 | USB Downloader Cable / set | 1 |
| PCle Fence | 1 |
Product Matrix
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
No documentation downloads are currently listed for this product on the manufacturer's website. Please contact our support for the user manual, schematics, and reference designs.
