The AXP390 model is high-end PANGOMICRO Titan2 device with fast DDR4 SDRAM, dual parallel quad SPI flash and thus forms a complete and powerful embedded processing system. This module is suitable for high-speed applications due to the high number of transceivers.
Compatible with a multitude of FMC board (data acquisition, motor control, display camera interfaces, software defined radio), Provide high-speed communication (PCIe, SFP+, QSFP+).

Applications

  • ● Communication

  • ● Image and video processing

  • ● Data analysis

  • ● Network information security

  • ● Instrumentation



Key Features

  • ● PANGO Titan-2 PG2T390H:◆ 28 nm FPGA fabric
    ◆ HSSTHP up to 13.125 Gbps Transceivers
    ● 8 GByte (64-bit) DDR4 SDRAM + 2 GByte (64-bit) DDR3 SDRAM
    ● 4 x 16 MB QSPI Flash
    ● 1 x PCIe® Gen3 ×8
    ● 4 x SFP+ (per line 10Gbps)
    ● 1 x QSFP+ (QSFP+ is 40Gbps)
    ● 1 x Gigabit Ethernet
    ● 1 x UART(USB to UART)
    ● 1 x Micro SD
  • ● 1 x Temperature sensor LM75A
    ● 1 x FMC LPC (34 pairs lvds ios)
    ● 1 x 40-pin Expansion Port (40 pin 2.54mm spacing, with 34 IOs, connected to ALINX modules such as binocular cameras, TFT LCD screens, high-speed AD modules, etc.)
    ● user I/Os
    ◆ 34 FPGA I/Os
    ● LED(1 x PWR + 4 x LED)  KEY(2 x KEY)
    ● 12V single supply
    ● Dimensions: 188 x 106 mm form factor

Product Information

  • Specifications
  • What's Inside
Development Board Features

Featuring the PANGOMICRO Titan2 PG2T390HFFBG900

Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any PANGOMICRO Titan2 based application.

What's Inside the Box

ALINX PANGOMICRO Titan2 PG2T390H development board and Some accessories

The FAN8060 Heatsink Kit is an optimal cooling solution for ALINX FPGA and  modules – it is low-profile and covers the whole module surface.

System-on-Module1Base Board1
Mini USB Cable1Heatsink Kit (preinstalled)1
12V Power Adapter1USB Downloader Cable / set1
PCle Fence1


Product Selection Matrix

Product Matrix

Product ModelPreferred ModelFPGA DevicesDDR4 ECC SDRAMQSPI FlashUSD Price
AXP392 √PG2T390H-6IFFBG9004 GB16 MB853
AXP391 √PG2T390H-6IFFBG9004 GB16 MB853
AXP390 √PG2T390H-6IFFBG9008 GB16 MB1947


1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.


We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.

Documentations

  • AXP390 User Manual

    2022-09-07
    Download
