Product Description
The AXP12 FPGA Development Board is PANGO Logos series device, delivers standout performance with SDRAM, QSPI Flash, HDMI, Gigabit Ethernet.
Applications
● Communication
● Industrial control
Key Features
System-on-Module
● PANGO Logos PGL12G:◆ 40 nm FPGA fabric
● Pluggable module with 2 x Panasonic board-to-board connectors
● 32 MByte (16-bit) SDRAM
● 16 MB QSPI FlashBase Board
● 1 x USB2.0
● 1 x HDMI out
● 1 x Gigabit Ethernet
● 1 x 512 Byte EEPROM 24LC04
● 1 x RTC (Real Timing Clock)
● 1 x Camera link
● 1 x UART (USB to UART)
● 1 x MicroSD
● LED (1 x PWR + 1 x RXD + 1 x TXD + 4 x LED) KEY (4 x KEY)
● 1 x 40-pin Expansion Port (40 pin 2.54mm spacing, with 34 IOs, connected to ALINX modules such as binocular cameras, TFT LCD screens, high-speed AD modules, etc.)
● 5V single supply
● Dimensions: 130 x 90 mm form factor
- Specifications
- What's Inside
Development Board Features
Featuring the PANGO Logos PGL12G-6CFBG256 Adaptive
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any PANGO Logos based application.
* The AXP12 development board consists of a P12 SoM and base board. If you want to purchase P12 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.
What's Inside the Box
ALINX PANGO Logos PGL12G development board and Some accessories
| System-on-Module | 1 | Base Board | 1 |
|---|---|---|---|
| Mini USB Cable | 1 | USB Downloader Cable / set | 1 |
| 5V Power Adapter | 1 | Acrylic Plate | 1 |
Product Matrix
1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.
We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
No documentation downloads are currently listed for this product on the manufacturer's website. Please contact our support for the user manual, schematics, and reference designs.
